Powereagle is 150-200W Adapter Power Supply manufacturer and supplier in China.
Low Price Quality 150-200W Adapter Power Supply In Stock. Powereagle is 150-200W Adapter Power Supply manufacturer and supplier in China.
Active PFC Function
Protections:Short circuit / Over voltage / Over current / Over temperature
Energy Efficiency Level VI or CoC Tier II
No Load Power Consumption ≤ 0.21W (VI), ≤ 0.15W (Tier II)
MTBF > 50,000 hours
X: AC inlet: 1. C14 2. C8 3. C6 6. C18
Y: Output range
vv: Specified output voltage, i.e. 12 is 12VDC
PP: DC plug type, i.e. Code 01 for 5.5x2.1mm or other options (refer to the appendix page)
OUTPUT
| Wattage | Output | VAC Universal Input | Frequency | AC Inlet | Case Size |
|---|---|---|---|---|---|
| 150W | 12~18VDC | 100~240VAC Universal Input | 50~60Hz | C14, C8, C6, C18 | 166L x 83W x 28H (mm) |
| 160W | 12~18VDC | ||||
| 170W | 12~18VDC | ||||
| 180W | 19~24VDC | ||||
| 180W | 32~42VDC | ||||
| 180W | 44~56VDC | ||||
| 190W | 19~24VDC | ||||
| 190W | 32~42VDC | ||||
| 190W | 44~56VDC | ||||
| 200W | 19~24VDC | ||||
| 200W | 32~42VDC | ||||
| 200W | 44~56VDC |
NOTE:
Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
Max. Power (W) ≥ Vo x Io
• Input Range 100 to 240 VAC
• Frequency 50 to 60Hz
• Input Current ≤ 2.5A
• Inrush Current ≤ 120A/230VAC
• Hold Up Time ≥ 8.3ms
• Turn On Time ≤ 3s
• Short Circuit Protection Latch-off
• Over Voltage Protection Latch-off
• Over Current Protection Latch-off
• Over Temperature Protection Latch-off
• Operating Temperature -20 to 40°C
• Storage Temperature -20 to 85°C
• Operating Humidity 10% to 90%
• Storage Humidity 5% to 95%
• Case Size: 166L x 83W x 28H (mm)
• AC Inlet: C14, C8, C6, C18
• Weight: 450g
Certified for whole series: UL 62368-1, CAN/CSA C22.2 No. 62368-1, TUV EN 62368-1, CB IEC 62368-1, FCC Part 15B, CE EMC(EN 55032+EN 55035), UKCA
